SMTE 8kW Hybrid Inverter – 48V Dual MPPT Pure Sine Wave Solar Inverter
SMTE 8kW Hybrid Inverter – 48V Dual MPPT Pure Sine Wave Solar Inverter
Take complete control of your energy independence with the 8kW Hybrid Inverter. Built for seamless home and commercial energy management, this advanced pure sine wave inverter supports up to 10,000W DC solar input, dual MPPT channels, and intelligent battery charging. Featuring an ultra-fast 10ms transfer time, it keeps your essential loads running without interruption during grid failures and power outages.
Key Features & Benefits
High 10,000W PV Input: Dual MPPT trackers (23A × 2) support up to 10kW of solar panel capacity for maximum energy harvesting and efficiency.
Flexible 48V Battery Management: Compatible with both Lithium-Ion and Lead-Acid battery banks (100–2000Ah) with direct BMS communication for optimized charging.
Rapid Charging & Discharging: Delivers up to 150A configurable charge current and 180A configurable discharge current for heavy-duty energy demands.
Seamless Backup Transition: Features a 10ms shift time between grid/bypass and inverter mode, preventing downtime for sensitive electronics and essential home loads.
Massive Surge Handling: Provides 8000W continuous output with a peak apparent power rating of up to 16,000VA to effortlessly start high-draw appliances.
Ultra-High Efficiency: Achieves up to 97.6% overall efficiency and 99.9% MPPT efficiency for minimal power loss.
Technical Specifications
PV String Input Parameters
Max. DC Input Power: 10,000W
Max. DC Input Voltage: 500V
Start-Up Voltage: 150V
MPPT Voltage Range: 120V – 450V
Max. Input Current: 46A (23A × 2 across 2 MPPT Channels)
MPPT Efficiency: 99.9%
Battery Input Parameters
Supported Battery Type: Lithium-Ion / Lead-Acid
Nominal Battery Voltage: 48V
Battery Input Voltage Range: 40V – 60V
Max. Charge Current: 150A (Configurable)
Max. Discharge Current: 180A (Configurable)
Max. Charge Voltage: ≤60V (Configurable)
Recommended Capacity: 100Ah – 2000Ah
BMS Communication: Direct CAN/RS485 communication with Li-Ion battery BMS
AC Output Parameters (Backup / Essential Load)
Rated Continuous Output Power: 8000W (8000VA)
Peak Output Apparent Power: 16,000VA
Max. Output Current: 36A
Nominal Output Voltage: 220V / 230V / 240Vac Single-Phase (Configurable)
Nominal Frequency: 50Hz / 60Hz (±0.2%)
Max. Bypass Current: 42A
Transfer / Shift Time: 10ms
THDv (Linear Load): <3%
Efficiency Ratings
Max. Efficiency: 97.6%
Europe Efficiency: 97.6%
Battery to Load Efficiency: 94.0%
