SMTE CPM170M-1 1.1KW (1.5HP) 220V Centrifugal Water Pump (170L/min, 36m Head, 1-1/4" × 1")

The SMTE CPM170M-1 1.1KW (1.5HP) Centrifugal Water Pump is an efficient, high-capacity water pump engineered to boost pressure and deliver dependable fluid transfer. Powered by a 220V 50Hz electric motor, this self-priming pump delivers a flow rate of up to 170 liters per minute (170L/min) and a maximum head height of 36 meters. With a 1-1/4″ inlet and 1″ outlet, it is ideal for residential waterline pressure boosting, multi-station garden irrigation, tank filling, and light commercial water systems.

Key Features
High-Output 1.5HP (1.1KW) Motor: Powerful single-phase electric motor ensures continuous water pressure and high-volume delivery.

High Flow & Head Capability: Produces up to 170L/min maximum flow rate with a 36m maximum vertical head elevation.

1-1/4″ Inlet & 1″ Outlet Ports: Sized to maintain steady suction and strong delivery pressure into existing piping and hose systems.

Self-Priming Performance: Engineered to simplify startup and maintain continuous pressure inside domestic waterlines.

Durable Cast Metal Construction: Heavy-duty casing with heat-dissipating cooling fins protects internal components and handles fluids up to 40°C.

12-Month Warranty Protection: Commercial-grade reliability backed by full 12-month manufacturer coverage.

Specifications
Brand: SMTE

Model: CPM170M-1

Motor Power: 1.1 kW (1.5 HP)

Rated Voltage: 220V AC (50Hz)

Pump Type: Self-Priming Centrifugal Water Pump

Maximum Flow Rate: 170 L/min

Maximum Head Height: 36 Meters

Inlet Port Size: 1-1/4 Inch (32 mm) Threaded

Outlet Port Size: 1 Inch (25 mm) Threaded

Max Fluid Temperature: 40°C

Housing Material: Cast Iron with External Cooling Fins

Warranty: 12 Months

What’s Included
1 × SMTE CPM170M-1 1.1KW (1.5HP) Centrifugal Water Pump

1 × Installation & User Guide
